Back Panel

Thermocouple (TC)

Thermocouple type "J" to measure temperature by contact. Screw or press against the surface that you want to measure the temperature, for example the engine block. The connection has polarity and it is a special cable that cannot be extended. The cables are pressure fit into the terminal block. Neatly strip 4mm of the insulation and insert. To remove, press the little white buttons on the terminal block.

Remote Control (SW)

Pushbutton input for controlling the software remotley.

Lambda Sensor (AFR)

Lambda probe input and auxiliary input.

Flywheel/Roller Rotation Sensor (RPM1)

RPM input from roller or flywheel sensor.

Engine RPM Sensor (RPM2)

Engine RPM input (sensor not included) or roller RPM input on AWD dynos.
